Bavarian Demon Axon 3-Axis Flybarless Gyro System

The Bavarian Demon Axon 3-Axis Flybarless Helicopter Gyro System has been developed from the depths of the underworld up for the most demanding levels of helicopter control, programming, and functionality. The Axon’s key feature is a built in Bluetooh transmitter which offers connectivity to Android & iOS devices for tuning & programming purposes. The latest 32 bit technology is utilized within the Axon design, incorporating new features such as 3 Bank Sets, Intelligent Vibration Analysis, & Governor functions for electric, nitro, & gasoline helicopters. Lastly the Axon is compatible with all current analog & digital serial Transmitter/Receiver protocols, which allows for compatible devices to communicate with each other for telemetry!

Features:

• Ultra-Precise Flight Control
• Latest 32-bit Technology
• Multiple Horizon & Rescue Modes
• 3 Bank Sets
• Integrated Governor
• Intelligent Vibration Analysis
• Android & iOS Compatible
• Multiple Protocol Input
• Online Updateable
• Prepared with Sensor Bus

Specifications:
Dimensions: 40x30x14mm
Supply Voltage: 4-10V (2s LiPo Compatible; Minimum 5.5V when using Spektrum or JR Satellites)
Max Roll & Pitch Rotational Speed: 500 degrees/sec
Max Tail Rotational Speed: 650 degrees/sec
Tail Servo Output: Digital: 166-333Hz; Analog: 55Hz; 760-1520uS
Head Servo Output: Digital: 166-333Hz; Analog: 55Hz
Maximum Servo Currents: 15A continuous, 18A peak
Weight: 27g
Cable Length: 150mm
